HM Series Modular Online UPS 40-400kVA (480V)

The HM Series Modular Online UPS delivers exceptional stability and scalability, designed specifically for large data centers across the Americas. Its compact footprint allows for a power density of 400kVA within a single cabinet. Up to 3 units can be paralleled for increased capacity or redundancy, supporting loads up to 1500kVA. Available power options include 80kVA, 160kVA, 240kVA, 320kVA, 400kVA, and 500kVA.

Key Features

Compact Design
Delivers 400kVA within a single cabinet with a footprint under 1.45m², optimizing valuable floor space.

High Power Density
Each 40kVA power module fits into a 4U height, enabling easy capacity expansion.

High Efficiency
Advanced 3-level technology ensures efficient double conversion operation, achieving up to 96% efficiency.

Intelligent Charging Management
The system intelligently manages the entire charging and discharging cycle, significantly extending battery life.

High Scalability
Configurations range from 40kVA to 400kVA in one cabinet, with up to three units parallelable for capacities up to 1200kVA.

User-Friendly HMI
Equipped with a 10.4” touch color LCD with graphical display, plus an independent LCD for each power module.

Smart Sleep Function
Automatically shuts down select power modules to increase overall load rate and boost efficiency.

Multiple Communication Interfaces
Supports RS232, RS485, USB, SNMP, AS400, and programmable dry contacts for flexible connectivity.
